Technical Specifications
Microphone Element |
Omni directional |
Microphone Sensitivity |
-40 dBV (0dB=1V/Pa) |
Speaker Output Power |
1 W |
Speaker Output Level (SPL) |
Up to 116+ dB (device dependent) |
Accessory Interface |
3.5 mm sealed Rx audio jack |
Dimensions |
79 mm x 65 mm x 29 mm |
Weight |
225 gm |
PTT |
High tactile |
Emergency |
Dedicated Red Button – PTT app dependent |
Volume Control |
RampClik™ one touch, 10 levels, ~2.5dB/level |
Remote Emergency |
Optional ELert™ remote emergency activation. See TruDock™ and HanzFree™ accessories |
Function Buttons |
Two – Optional feature and/or PTT app dependent |
Battery |
1,100 mAh Li-On |
Battery Life – Normal Use |
24 Hours |
Charging |
USB C to USB A cable included |
Charging, Remote |
TruDock™ charging, docking & mounting solutions |
Low Battery Warning |
Audible (beep) & visual (LED) |
PTT App Compatibility |
User configurable, supports Zello and Kodiak-based apps |
Rotating Belt Clip |
360° w/ positive detents every 45° / Replaceable / Optional button post |
Mining/Industrial Rx Audio Protection |
Optional MagShield™ acoustic speaker shroud |
Immersion |
Designed to meet IP68 |
Printed Circuit Board (PCB) |
Surface mount technology (SMT). 100% gold plated contacts. |
Warranty |
24 month, excluding battery |
Designed to meet: Mil-Std 810H
Low Pressure 500.6/1 |
High Temp 501.7/I & II |
Low Temp 502.7/I & II |
Temp Shock 503.7/I |
Solar Radiation 505.7/II |
Blowing Rain 506.6/I |
Humidity 507.6/II |
Salt Fog 509.7/I |
Sand & Dust 510.7/I |
Immersion 512.6/I |
Vibration 514.8/I/CAT 1 |
Shock 516.8/I & IV |
